LC Fiber Optic Adapter single mode duplex blue color with ears welded type
- 25Pack LC-LC Duplex Fiber Optic Couplers/Adaptors to join two fiber patch cables together. Securely connect your 62.5/125 multimode, 50/125 multimode or 9/125 singlemode fiber optic patch cables.
- Product Type: Fiber Optic
- Connector 1: LC Duplex (with clip), a small form factor connector that uses a 1.25 mm ceramic ferrule.
- Connector 2: LC Duplex (with clip), a small form factor connector that uses a 1.25 mm ceramic ferrule.
- Warranty: Lifetime - All FiberCablesDirect products come with a lifetime warranty. If it stops working when it shouldn't, we'll replace it free.
- Color : single mode is blue / green color ( also can be customized according to your requirements )
- multi mode have beige / Aqua /purple/ rose ,etc ( can be customized according to your requirements
- Adapter have simplex / duplex / four cores / 8 cores / 16 cores
- Mode type : adapter has single mode ( UPC / APC ) and multi mode
- Adapter type : LC / SC / FC / ST / MPO
- Material : plastic / metal
| Insertion loss(typical) | ≤0.3dB |
| Interchangeability | ≤ 0.2dB |
| Vibration | ≤ 0.2dB |
| Repeatability | ≤ 0.2dB |
| Durability | >1000 times |
| Operating temperature | -40˜75°c |
| Storage temperature | -45˜85°c
|
Prameter
| Product Name | Sm big high telecom / apc d-hole adaptor small d type fc fiber optical adapter fc/upc d-type |
| Modle Number | FC D-type Adapter |
| Inserion Loss | ≤0.3dB |
| Durability | >1000 times |
| Operating Temp | -40~70°C |
| Material | Metal |
| Application | FTTx,LAN,CATV,Telecom |
| Certification | RoHS,SGS,CE |
| Connector Type | FC-FC |
| Polish Type | UPC;APC |
| Fiber Mode | Singlemode; Multimode; OM3; OM4;OM5 |
| Color | SM:Blue,Green MM:Beige OM3:Aqua OM4:Violet OM5:Lime green |
| Core | Simplex |
| Flange | with flange/with ear; |
| Form of sale | Neutral/OEM/ODM |
| Use | Fiber connection |
| Custom Design | welcom |
| Sample Lead Time | within 7 days after confirmation |
| Advantage | Best price,best service |
| Payment Terms | T/T in advance; Others(subject to negotiation between both parties) |
More picture
Company introduction
New Light Optics Technology Limited specialized in the Optical communication products R & D, manufacture,sales and service as high-tech company.Our factory was established in 2011 and with 6 years OEM and manufacture experience for customer all over the world.
Our product line include: Patch Cord/Pigtails,Patch Cord Cables,MTP/MPO Patch Cord,Fiber Optical adapter( SC adapter , LC adapter ,FC adapter ,ST adapter,MPO adapter, MPO attenuator, attenuator Fiber optical connector... Etc.
Our products widely used in Telecommunication,Fiber optical CATV, digital internet fiber transmit,data base station,etc.
Company have high tech technology, professional R & D team, advanced production equipment,sophisticate skill engineers. And high quality control system,our products offer to customers to USA,European,Brazil,Middle East,and Asia more than 60 countries and areas.
Products received high reputation and feedback from all customers!
Please contact us if any we can support and cooperate together!
Delivery and payment
1. Delivery time : 2-15 working days after received payment
2.package: export sdandard package
3. payment term: T/T ,PAYPAL,westen union ,L/C . 30% deposit , 70%balance paid before delivery
4.warranty : 3 years
5.Delivery method : by aire ( DHL, UPS,FEDEX ,TNT,etc ) by sea
